FRAME
Alloy Frame / single pivot / Trunnion shock mount
Boost 148x12mm / 120mm travel
Tapered Headtube E2 / Shimano E-8000 Int. DT Battery

FORK
FOX 34 Float Performance Elite Air
FIT4 3-Modes with low Speed adj. / 15x110mm QR axle
tapered steerer / Reb. Adj. / Lockout / 130mm travel / E-Bike

REAR SHOCK
FOX NUDE EVOL Trunnion
Contessa Custom Tune / geo adj.
3 modes: Lockout - Traction Control -Descend
DPS / EVOL / Reb. Adj.
Travel 120 - 85 - Lockout / 165X45mm

E.DRIVE SYSTEM
Shimano STEPS E8000
250W w/integr. 500Wh Battery / Shimano Charger

REMOTE SYSTEM
SCOTT TwinLoc Remote Technology
3 modes front and rear / integ. Grip clamp

HEADSET
Syncros FL2.0 Press Fit E2 / Tapered 1.5" - 1 1/8"
OD 50/62mm / ID 44/56mm

REAR DERAILLEUR
Shimano XT RD-M8000 SGS
DM / Shadow Plus / 11 Speed

FRONT DERAILLEUR
SCOTT Chainguide

SHIFTERS
Shimano XT SL-M7000-I / Rapidfire Plus
2 way release / Ispec 2 clamp

BRAKES
Shimano XT M8000 Disc
203mm F & R / SM-RT64 CL Rotor

CRANKSET
Shimano STEPS FC-E8050 34T

HANDLEBAR
Syncros FL1.5 STEPS mini Riser / Alloy 7075 D.B.
12mm rise / 9° / 740mm
Syncros WS Pro lock-on grips

H'STEM
Syncros FL1.5 / Alloy 2014
integrated Spacer & Top Cup / 31.8mm / 6° / 1 1/8"

SEATPOST
FOX Transfer Dropper Remote
31.6mm / S size 100mm / M 125mm / L 150mm

SEAT
Syncros FL2.0 WS / CRMO rails

HUB (FRONT)
Formula CL811 / 15x110mm

HUB (REAR)
Formula CL14811 / Boost 12x148mm

CHAIN
Shimano CN-HG601

CASSETTE
Shimano XT CS-M8000 11-46 T

SPOKES
Stainless Black

RIMS
Syncros X-30S / 32H / 30mm / Sleeve Joint
Tubeless ready

TIRES
Maxxis Rekon / 2.80 x 27.5 / 120TPI Kevlar Bead
EXO / TR Tubeless ready
Front: 3C Maxx Terra / Rear: 3C Maxx Speed
