FRAME
Scale 700 Alloy
Custom Butted Superlight Tubing / Tapered HT
BB92 / 3.0" Tire clearance / Full Internal Cable Routing
IDS SL dropouts for 12x148mm Boost

FORK
FOX 32 Float Rhythm
Grip 3 / 3-Modes / 15x110mm QR axle / tapered steerer
Reb. Adj. / Lockout / 120mm travel

REMOTE SYSTEM
SCOTT RideLoc RSP Technology
Suspension - Seatpost Remote
below Bar / 3 modes / integ. Grip clamp

HEADSET
Syncros Pro Press Fit / Tapered 1.5" - 1 1/8"
OD 50/61mm / ID 44/55mm

REAR DERAILLEUR
Sram GX / Eagle 12 Speed

SHIFTERS
Sram GX Trigger

BRAKES
Shimano Deore M6000 Disc
180/F and 160/R mm SM-RT64 CL Rotor

CRANKSET
Sram X1 1000 Eagle GXP Boost PF
QF 168 / 32T

BB-SET
Sram GXP PF integrated / shell 41x89.5mm

HANDLEBAR
Syncros FL1.5 mini Riser / Alloy 7050D.B.
12mm rise / 9° / 740mm
Syncros Pro lock-on grips

H'STEM
Syncros FL2.0 / 6061 Alloy
6° / integrated Top Cup / 31.8mm / 1 1/8"

SEATPOST
Syncros Dropper 2.0 Remote
31.6mm / 120mm

SEAT
Syncros XM2.0 / CROM rails

HUB (FRONT)
Formula CL811 / 15x110mm

HUB (REAR)
Formula CL14811 / Boost 12x148mm / XD

CHAIN
Sram CN GX Eagle

CASSETTE
Sram GX / XG1275 / 10-50 T

SPOKES
Stainless Black 15G / 1.8mm

RIMS
Syncros X-30S / 32H / 30mm / Sleeve Joint
Tubeless ready

TIRES
Maxxis Rekon / 2.80x27.5 / 60TPI Kevlar Bead
TR Tubeless ready
