FRAME
Scale 3 Carbon / IMP technology / HMF
BB92 / SW DM dropouts for Boost 12x148mm
SDS2 advanced Shock & Standing Damping System
ICCR Cable routing

FORK
FOX 32 SC Float Performance Elite Air
FIT4 3-Modes with low Speed adj. / 15x110mm QR axle
tapered steerer / Lockout / Reb. Adj.
100mm travel

REMOTE SYSTEM
SCOTT RideLoc Technology / below bar remote
3 modes / integ. Grip clamp

HEADSET
Syncros Pro Drop in / Tapered 1.5" - 1 1/8"
bearing diameter size 42mm and 52mm

REAR DERAILLEUR
Sram X01 / Eagle 12 Speed

SHIFTERS
Sram GX Trigger

BRAKES
Shimano XT M8000 Disc
180/F and 160/R mm SM-RT64 CL Rotor

CRANKSET
Sram GX Eagle GXP Boost PF
QF 168 / 32T

BB-SET
Sram GXP PF integrated / shell 41x89.5mm

HANDLEBAR
Syncros FL1.5 T-Bar / Alloy 7050 D.B.
T shape Flat / 9° / 720mm
Syncros Pro lock-on grips

H'STEM
Syncros FL1.5
6° / integrated Spacer & Top Cup
2014 Alloy / 31.8mm / 1 1/8"

SEATPOST
Syncros FL1.5 / 10mm offset
31.6 x 400mm

SEAT
Syncros XR1.5 / Titanium rails

WHEELSET
Syncros XR2.0 CL
F: 15x110mm, R: 12 x 148mm Boost
25mm Tubless ready rim / 28H / XD / DT RWS

CHAIN
Sram CN GX Eagle

CASSETTE
Sram GX / XG1275 / 10-50 T

TIRES
Maxxis IKON / 2.25 / 120TPI Kevlar Bead
TR Tubeless Ready / EXO / 3C maxx Speed
