FRAME
Scale 3 Carbon / IMP technology / MF
BB92 / SW DM dropouts for Boost 12x148mm
SDS2 advanced Shock & Standing Damping System
ICCR Cable routing

FORK
FOX 32 Float Rhythm
Grip 3 / 3-Modes / 15x110mm QR axle / tapered steerer
Reb. Adj. / Lockout / 100mm travel

REMOTE SYSTEM
SCOTT RideLoc Remote Technology
3 modes / integ. clamp

HEADSET
Syncros Pro Drop in / Tapered 1.5" - 1 1/8"
bearing diameter size 42mm and 52mm

REAR DERAILLEUR
Shimano XT RD-M8000 SGS
DM / Shadow Plus / 22 Speed

FRONT DERAILLEUR
Shimano SLX FD-M7020-11D / side swing

SHIFTERS
Shimano SLX SL-M7000-11-I / Rapidfire Plus
2 way release / Ispec 2 clamp

BRAKES
Shimano SLX M7000 Disc
180/F and 160/R mm SM-RT64 CL Rotor

CRANKSET
Shimano XT FC-M8000-B2 / Hollowtech 2
34x24 T

BB-SET
Shimano BB-MT500-PA / shell 41x92mm

HANDLEBAR
Syncros FL2.0 T-Bar / Alloy 6061
T shape Flat / 9° / 720mm
Syncros Pro lock-on grips

H'STEM
Syncros FL2.0
6° / integrated Spacer & Top Cup
6061 Alloy / 31.8mm / 1 1/8"

SEATPOST
Syncros FL2.0 / 10mm offset
31.6 x 400mm

SEAT
Syncros XR2.0 / CROM rails

HUB (FRONT)
Shimano HB-M6010-B CL / 15x110mm

HUB (REAR)
Shimano FH-M6010-B CL / Boost 12x148mm

CHAIN
KMC X11EL

CASSETTE
Shimano SLX CS-M7000 / 11-42 T

SPOKES
Stainless Black 15G / 1.8mm

RIMS
Syncros X-25S / 32H / 25mm / Sleeve Joint
Tubeless ready

TIRES
Maxxis Ikon / 2.2 / 60TPI Kevlar Bead
TR Tubeless Ready / Dual compound
