FRAME
Scale 3 Carbon / IMP technology / HMF
BB92 / SW DM dropouts for Boost 12x148mm
SDS2 advanced Shock & Standing Damping System
ICCR Cable routing

FORK
FOX 32 Float Rhythm
Grip 3 / 3-Modes / 15x110mm QR axle / tapered steerer
Reb. Adj. / Lockout / 100mm travel

REMOTE SYSTEM
SCOTT RideLoc Technology / below bar remote
3 modes / integ. Grip clamp

HEADSET

Syncros Pro Drop in / Tapered 1.5"-1 1/8"
bearing diameter size 42mm and 52mm

REAR DERAILLEUR

SRAM NX / Eagle 12 Speed


SHIFTERS
SRAM NX Eagle Trigger

BRAKES
Shimano MT400 Disc180/F and 160/R mm
SM-RT54 CL Rotor

CRANKSET
SRAM NX Eagle DUB Boost
32T

BB-SET

SRAM DUB PF integrated / shell 41x92mm

Chainguide
SCOTT custom

HANDLEBAR
Syncros FL2.0 T-Bar / Alloy 6061
T shape Flat / 9° / 720mm
Syncros Pro lock-on grips

H'STEM

Syncros FL2.06° / integrated Spacer & Top Cup
6061 Alloy / 31.8mm / 1 1/8"

SEATPOST

Syncros FL2.5
31.6x400mm

SEAT
Syncros XR2.0 / CROM rails

HUB (FRONT)
Shimano HB-MT400-B CL / 15x110mm

HUB (REAR)

Shimano FH-MT400-B CL / Boost 12x148mm

CHAIN

SRAM CN NX Eagle

CASSETTE

SRAM NX / XG1230 / 11-50 T

SPOKES
Stainless Black 15G / 1.8mm

RIMS

Syncros X-25 / 32H / 25mm
Tubeless ready

TIRES
Maxxis Rekon Race / 2.25" / 60TPI Kevlar Bead
TR Tubeless Ready / EXO
